7" TFT Display (TFT070A102C)
This 7" WVGA resolution display features an 800 cd high power backlight.
This makes it well suited to high brightness environments and remains clear and vivid in use.
It also delivers an extended backlight half-life of 50K hours, making it ideal for always-on applicaitons.
Display Features
- Size: 5" - 9"
- Type: TN TFT
- Feature: High Brightness
- Feature: Industrial Backlight
Display Specs
| Part Number | TFT070A102C |
| Display Type | TN TFT |
| Screen Size | 7" |
| Resolution | 800 x 480 |
| Shape | Standard |
| Aspect Ratio | 5:3 |
| Viewing Angle | 12 o'clock |
| Brightness | 800 cd/M² |
| Backlight Half-Life | 50K Hours |
| Contrast Ratio | 500:1 |
| Interface | RGB |
| Connection | ZIF |
| Operating Temperature Range | -20°C to 70°C |
| Dimensions (W x H x D) | 164.9 x 100 x 5.6 mm |
| Active Area (W x H) | 153.8 x 85.6 mm |
