Letterbox Displays
Letterbox displays, also known as bar displays, are ideal for applications with more challenging form factors.
With their low height and extra width, these displays are excellent for designs with limited build height, and can fit where standard aspect ratios are just too tall and too narrow to look right on a front panel.
Their unique form factor makes them ideal for applications such as 1U rack mount systems or high end and professional grade Hi-Fi systems, while still providing plenty of display area for complex user interfaces.
Our range of enhancements and customisation options is available across the range, meaning we can fully tailor these displays to your application.
This 2.9" IPS TFT is one of the smallest panels in our range of letterbox TFTs and features an aspect ratio of nearly 3:1.
- Resolution: 320 x 120
- Interface: RGB
- Brightness: 300 cd/M²
- Contrast: 300:1
- Temperature: -20°C to 70°C
Find out more
This 2.9" display is the smallest IPS panel in our range of letterbox TFTs. It features an aspect ratio of 2.5:1 making it ideal for 19" rack applications.
- Resolution: 376 x 960
- Interface: MIPI, RGB, SPI
- Brightness: 300 cd/M²
- Contrast: 1,000:1
- Backlight: 20K Hours
- Temperature: -20°C to 70°C
Find out more
This 3.9" display is one of the smallest in our range of letterbox products and comes with an anti-glare coating as standard.
- Resolution: 480 x 128
- Interface: RGB
- Brightness: 600 cd/M²
- Contrast: 500:1
- Temperature: -20°C to 70°C
Find out more
This 4.6" display is part of our range of letterbox products and comes with an anti-glare coating as standard.
- Resolution: 800 x 320
- Interface: RGB
- Brightness: 520 cd/M²
- Contrast: 500:1
- Temperature: -20°C to 70°C
Find out more
This 5.8" ultra-wide TFT features a 24-bit RGB interface and an aspect ratio of 2.5, and is polarised for a 12 o'clock viewing angle.
- Resolution: 800 x 320
- Interface: RGB
- Brightness: 500 cd/M²
- Contrast: 600:1
- Backlight: 25K Hours
- Temperature: -30°C to 85°C
Find out more
This 6" letterbox IPS display has a high brightness rating and extended backlight half-life, wrapped up in 1:2 aspect ratio.
- Resolution: 1080 x 2160
- Interface: MIPI
- Brightness: 1,000 cd/M²
- Contrast: 1,200:1
- Backlight: 50K Hours
- Temperature: -20°C to 70°C
Find out more
This 6.8" letterbox IPS display has a thin profile and narrow bezels, making it ideally designed for up-to-the-edge mounting.
- Resolution: 480 x 1280
- Interface: MIPI
- Brightness: 400 cd/M²
- Contrast: 900:1
- Backlight: 20K Hours
- Temperature: -20°C to 60°C
Find out more
This 7" letterbox IPS display features an integral serial port, which makes it easier for OEMs to configure and communicate with the display.
- Resolution: 1424 x 180
- Interface: MIPI
- Brightness: 400 cd/M²
- Temperature: -20°C to 70°C
Find out more
This 7.8" IPS TFT is one of our mid-sized letterbox displays. It offers an aspect ratio of just over 3:1 and is ideal for consumer audio electronics.
- Resolution: 1280 x 400
- Interface: MIPI
- Brightness: 500 cd/M²
- Contrast: 900:1
- Backlight: 20K Hours
- Temperature: -20°C to 70°C
Find out more
This 8.8" letterbox IPS display has an excellent contrast ratio and all-round viewing angles, and delivers a wide 1:4 aspect ratio.
- Resolution: 480 x 1920
- Interface: MIPI
- Brightness: 600 cd/M²
- Contrast: 800:1
- Backlight: 30K Hours
- Temperature: -20°C to 70°C
Find out more
This 9" letterbox display features all the benefits of IPS in addition to an extended operating temperature range of -30°C to 85°C.
- Resolution: 1280 x 240
- Interface: LVDS
- Brightness: 600 cd/M²
- Contrast: 1,000:1
- Backlight: 25K Hours
- Temperature: -30°C to 85°C
Find out more
This 10.25" letterbox TFT display features an HD resolution and an IPS panel, delivering all-round viewing angles, high contrast and excellent response times.
- Resolution: 1920 x 720
- Interface: LVDS
- Brightness: 600 cd/M²
- Contrast: 900:1
- Backlight: 50K Hours
- Temperature: -30°C to 85°C
Find out more
This 11" display features our widest letterbox display aspect ratio at nearly 11:1, making it ideal for extremely low height designs.
- Resolution: 1280 x 120
- Interface: RGB
- Brightness: 750 cd/M²
- Contrast: 600:1
- Temperature: -10°C to 60°C
Find out more
This 12.3" TFT display is the largest in our range of letterbox products and features a high resolution screen.
- Resolution: 1920 x 720
- Interface: LVDS
- Brightness: 1,000 cd/M²
- Contrast: 1,000:1
- Backlight: 70K Hours
- Temperature: -30°C to 85°C
Find out more
